Home » Products » Arbors, Knurling Tool Holders

Arbors, Knurling Tool Holders

Arbors, Knurling Tool Holders
Arbors, Knurling Tool Holders
Product Code : AK-08
Brand Name : HTC
Product Description
HTC-3601, HTC- 3711, HTC-3800

SLITTING OR SLOTING SAW ARBOR (SAW HOLDER)
  • Versatile holders offer flexibility in sawing operations.
  • Spring loaded mechanism readily accepts saw blades with hole diameter from ½” to 1”.
  • Blades are firmly secured in position with hex headed screw.
#
Dia of Shank
Overall Length
Holes Sizes
HTC – 3601
1/2"
2-1/8”
1/2",5/8”,3/4”,7/8” & 1”
HTC – 3602
R-8

1/2",5/8”,3/4”,7/8” & 1”

KNURLING TOOL HOLDER 3700 ( 3711)
  • Machined and ground.
  • Equipped with high speed steel knurls.
  • Single knurl tool is equipped with medium cut high speed steel knurl.
  • Two knurls tool is generally provided with medium knurls but other knurls can also be provided if required.
  • Six knurls tool is provided with one pair each of fine, medium and coarse knurls.
  • Shiny black finish.
#
Size of Holder
Dia
Knurl Dimension Face
Hole
NO. of Knurls
HTC – 3711
1/2"X1/2”X4”
3/4"
1/4"
1/4"
1
HTC – 3722
1/2"X1/2”X4-1/2”
3/4"
3/8”
1/4"
2
HTC – 3732
5/16”X3/4”X5”
5/8”
5/16”
7/32”
2
HTC – 3742
3/8”X7/8”X5-1/2”
5/8”
5/16”
7/32”
2
HTC – 3752
½”X1-1/8”X6-1/2”
3/4"
3/8”
1/4"
2
HTC – 3762
5/8”X1-3/8”X7-1/2”
3/4"
3/8”
1/4"
2
HTC – 3716
5/16”X3/4”X5”
5/8”
5/16”
7/32”
6
HTC – 3726
3/8”X7/8”X5-1/2”
5/8”
5/16”
7/32”
6
HTC – 3736
½”X1-1/8”X6-1/2”
3/4" 3/8”
1/4" 6
HTC – 3746
5/8”X1-3/8”X7-1/2”
3/4" 3/8”
1/4" 6

KNURLS

AVAILABLE IN H.S.S AND HS.

#
Dia
Width
Bore
Pitch
HTC - 3781
5/8
5/16
7/32
14,21,33
HTC – 3782
3/4
3/8
1/4
14,21,33
HTC – 3783
1
3/8
5/16
14,21,33
HTC – 3784S
SET OF SIX 5/8”X5/16”X7/32” (CORASE, MED. AND FINE)
HTC – 3785S
SET OF SIX ¾”X3/8”X1/4” (COARSE, MED. AND FINE)
HTC – 3786 S
SET OF SIX 1”X3/8”X5/16” (COARSE, MED. AND FINE)

FLY TOOL CUTTER HOLDER
  • Made of hardened steel.
  • Counterbalanced to get smoother finishes.
  • Machines up to 6” wide surface with standard tool bits.
  • Three sizes per set in shiny black finish.
  • Available in individual sizes.
  • Sets supplied along with a wooden stand.
#
Head Dia
Shank Size
Tool Bit
HTC – 3801 A
3/4"
1/2"
3/16”
HTC – 3801 B
1-1/8”
1/2"
1/4"
HTC – 3801 C
1-1/2”
1/2"
5/16”
HTC – 3801 S
SET OF 3 PCS. (ONE
EACH OF ABOVE)


HTC – 3802 A
1-1/2”
3/4"
5/16”
HTC – 3802 B
2”
3/4"
5/16”
HTC – 3802 C
2-1/2”
3/4"
5/16”
HTC – 3802 S
SET OF 3 PCS. (ONE
EACH OF ABOVE)


HTC – 3803
2-1/2”
R-8
5/16”
